Author Topic: My 1/10 RCs WARNING Lots and lots of pics.(Dw itll be in spoilers) ;D  (Read 3120 times)

QuangVuong

  • Commodore
  • *******
  • Offline Offline
  • Posts: 808
  • BANNED!
    • View Profile

Yokomo BD

Make: Yokomo
Model: BD

Date: 18.5.11
Track surface: Smooth Cement
Tire: Drifter Street
Motor & ESC: Reedy Stockstar and Novak GT7
Front

Camber: 0 deg
Toe: 0 deg
Kick up: 1mm
Caster hubs: Removed
Ride height: 5mm
Springs: Yokomo Blue(Hard)
Bumper weight: IFS
Trailing Steering Block: Stock
Sway-Bar: None
Shock Oil: 30wt
Other: Caster mod (10+ deg)

Rear

Camber: 0 deg
Toe: +1 deg
Kick up: 0mm
Ride height: 5mm
Springs:  Yokomo White(Soft)
Sway-Bar:None
Shock Oil:30wt
Other:

Drive Train

Gearing:
Front: Yokomo 40t
Center: Front Colt 15t / Rear Yokomo 20t
Rear: Colt 32t
Spur: 78
Pinion: 23
Other:
Belts are stock front and Schumacher 60t. A no tensioner setup would be a Cyclone front belt and a TRF416 rear belt.

Front 40x15, Rear 32x20. About 67% CS.

















Castor and Camber at 13 deg on max lock
Outer Wheel


Inner Wheel



Tamiya TA-05 with a Fijon Conversion
From This...




To this...












Top View


Underside View






Steering


No Ackerman. I modded mine so theres no ackerman and I have max lock.




Build HERE!
Spoiler (click to show/hide)

HPI Sprint 2
Chassis: HPI Sprint 2
Radio: Spektrum
Motor: Venom 8.5t Sensored
ESC: Venom 120A Sensored ESC
Servo: Spektrum Z270 Standard Race Servo

Full Silver Alloy Hop Ups

CS Ratio = 50%
Front 32t/10t and rear 15t/32t

FINISHED



Hardly any right lock


But max left lock. Gotta fix it somehow.
















Front Mounted Servo, and crazy steering angle. Done by the owner.






Build HERE
Spoiler (click to show/hide)

Bodies
APR R35
This was part of a BBO on SRCD.
To be used:
R35
3D Carbon Sheets
Hobby Knife
Scissors
Tamiya PS1 White Paint
Kyosho Micron Line Tape 0.4mm
R2 Hobbies Spoiler
Mesh
Chrome Stickers
Texta for the exhausts
Light Set

Spoiler (click to show/hide)

Update-9.5.11-JDM 4 LIFE
Finished now!




















Team Toyo R34
























WIP HERE
Spoiler (click to show/hide)
Logged


Canon 1Ds 24-105mm f4L
(\__/)
(=
'.'=)
(")_(")

fury-s12

  • Administrator
  • Vice Admiral
  • *****
  • Offline Offline
  • Posts: 4786
    • View Profile

Very nice I had a ta05 for a while such a fun thing to slide about with but was a hobby I couldn't afford really so sold it  would love another one though, I like the r34 too nice body, yokomo and the d1 bodies ftw though
Logged

QuangVuong

  • Commodore
  • *******
  • Offline Offline
  • Posts: 808
  • BANNED!
    • View Profile

Really you cant afford RC stuff, but you can afford Gundams. If you check around on RCtech, some chassis sell for about $50-$100. Cheap way to get back into it.As long as you dont break too many tihngs, then its a relatively cheap hobby.

Thanks. That R34 has a borken lip now, and was my 2nd body I painted. Yokomo BD was my second chassis after a TL-01. That has been through 5 owners before I bought it. Needs a rebuild sooner or later.
Logged


Canon 1Ds 24-105mm f4L
(\__/)
(=
'.'=)
(")_(")

fury-s12

  • Administrator
  • Vice Admiral
  • *****
  • Offline Offline
  • Posts: 4786
    • View Profile

i could afford one now i imagine haven't looked back into it tbh having too much fun with gundam but a few years ago wen i had the thing i couldnt afford 2 min noodles lol
Logged

QuangVuong

  • Commodore
  • *******
  • Offline Offline
  • Posts: 808
  • BANNED!
    • View Profile

Lol. Ill keep an eye out for a cheap chassis and let you know.

If you go on to RCtech, theres a guy down in Tassie, who prob has past RC chassis lying around. Ive bought stuff from him before. Forum name: addicted
Logged


Canon 1Ds 24-105mm f4L
(\__/)
(=
'.'=)
(")_(")

fury-s12

  • Administrator
  • Vice Admiral
  • *****
  • Offline Offline
  • Posts: 4786
    • View Profile

might just look into it thanks man
Logged

QuangVuong

  • Commodore
  • *******
  • Offline Offline
  • Posts: 808
  • BANNED!
    • View Profile
« Last Edit: May 29, 2011, 04:11:47 PM by QuangVuong »
Logged


Canon 1Ds 24-105mm f4L
(\__/)
(=
'.'=)
(")_(")

Feotus

  • Lieutenant Junior Grade
  • **
  • Offline Offline
  • Posts: 27
    • View Profile


I was hoping I could put some R/C stuff here. I don't have photos yet. I have built a Tamyia M, Rising Fighter. HPI F10. I currently finshing a Kyosho Giga Crusher SF. I know Nitro is quicky being pasted by brushless. I wanted to buld one before they get tough to get.
Logged

QuangVuong

  • Commodore
  • *******
  • Offline Offline
  • Posts: 808
  • BANNED!
    • View Profile

If you want to go ahead.

Good to hear that there are other RCers here.
